Vacuum Fish Pump BAPV-D Series
CB Vacuum Fish Pump System for Fish Processing is specially designed for fish transfer in pre-processing stage. It enables efficient fish transfer: lifting fish from fishing vessels to processing plants, or feeding fish from bunkers to processing lines.
It operates on the working principle of “vacuum negative pressure suction and positive-pressure air conveying”. Fish do not contact with moving mechanical parts. With optimized tank and system design, supporting efficient transfer of all types of catch, effectively reducing fish damage and improving product yield.
With different capacity combination and flexible modular equipment layout, the system perfectly fits different application scenarios, including fishing vessels, processing trawlers, and land-based processing plants using caught-fish as raw material. This series is an ideal option to achieve efficient, automated and low-damage transfer for fishing and onboard processing operations.
-
+Control Cabinet
-
+Outlet Valve Cone
-
+Suction Inlet (To connect suction pipeline)
-
+Air-water Separator
-
+Liquid ring Compressor
-
+Vacuum Tank (316L Stainless Steel)
Product Features
Designed for transfer of various species. Smooth tank surface and flow tunnels minimize physical damage to fish. Tank from 316L stainless steel compatible to harsh seawater environment. Equipped with top level liquid ring compressor to ensure reliable and stable operation. Excellent conveying capacity with wide operating range with maximum suction lift up to 8 m, maximum discharge lift up to 15 m. Fitted with high efficiency gas water separator for effective separation of water from exhaust gas. Variable frequency drive (VFD) to have flexible conveying flow according to actual processing output and transfer requirements. Automatic control system with convenient local panel operation, and support interaction with remote control system.
Product Advantages
Designed for various caught-fish species. No moving mechanical components inside the system, which greatly reduces fish injury and preserves fish integrity. Delivers high volume transfer with outstanding conveying efficiency, eliminating production bottlenecks and boosting processing line throughput. Supports long distance transfer and adapts to complex pipeline layouts, perfectly suitable for diverse processing scenarios. Effectively replaces intensive manual operations. Eliminate cumbersome manual handling and reduce labor cost. Extremely simple operation, equipment can be easily operated by normal operators. Compact mechanical structure with few wearing parts, ensuring high equipment reliability and long service life.
Product Specification
BAPV-300S55S-D
BAPV-300S45D-D
BAPV-450S55D-D
| Power Supply (V/Phase/Hz) | 400V / 3Ph / 50Hz |
| Liquid Ring Compressor | OMS1000 |
| Rated Power (kW x Qty) | 55 x 1 |
| Vacuum Tank Model | BATV-300-D |
| Volume x Qty.( m3 x Qty) | 3.0 x 1 |
| Inlet/Outlet Port Size mm(inch) | 325mm (12”) |
| Performance (Fish + water)*1 |
| Max. Suction Height (m) | 8 |
| Max. Discharge Height (m) | 15 |
| 8m Suction & 15m Discharge (m3/h) | 56 |
| 6m Suction & 10m Discharge (m3/h) | 120 |
| Reference Fish Size *2 (kg) | Up to 8 |
| Outlet Valve Cone Model | BAOV-300S-D |
| Inlet Port Size mm(inch) | 325mm(12”) |
| Outlet Port Size mm(inch) | 325mm(12”) |
| Power Supply (V/Phase/Hz) | 400V / 3Ph / 50Hz |
| Liquid Ring Compressor | OMS700 |
| Rated Power (kW x Qty) | 45 x 2 |
| Vacuum Tank Model | BATV-300-D |
| Volume x Qty. (m3 x Qty) | 3.0 x 1 |
| Inlet/Outlet Port Size mm(inch) | 325mm (12”) |
| Performance (Fish + water)*1 |
| Max. Suction Height (m) | 8 |
| Max. Discharge Height (m) | 15 |
| 8m Suction & 15m Discharge (m3/h) | 90 |
| 6m Suction & 10m Discharge (m3/h) | 150 |
| Reference Fish Size *2 (kg) | Up to 8 |
| Outlet Valve Cone Model | BAOV-300S-D |
| Inlet Port Size mm(inch) | 325mm(12”) |
| Outlet Port Size mm(inch) | 325mm(12”) |
| Power Supply (V/Phase/Hz) | 400V / 3Ph / 50Hz |
| Liquid Ring Compressor | OMS1000 |
| Rated Power (kW x Qty) | 55 x 2 |
| Vacuum Tank Model | BATV-450-D |
| Volume x Qty. (m3 x Qty) | 4.5 x 1 |
| Inlet/Outlet Port Size mm(inch) | 375mm (14”) |
| Performance (Fish + water)*1 |
| Max. Suction Height (m) | 8 |
| Max. Discharge Height (m) | 15 |
| 8m Suction & 15m Discharge (m3/h) | 112 |
| 6m Suction & 10m Discharge (m3/h) | 240 |
| Reference Fish Size *2 (kg) | Up to 12 |
| Outlet Valve Cone Model | BAOV-350S-D |
| Inlet Port Size mm(inch) | 375mm(14”) |
| Outlet Port Size mm(inch) | 375mm(14”) |
Note：
*1.Performance depends on actual suction height and discharge height.
*2.This size is according to salmon or trout. For others, it depends on fish species or its profile.
