Speed Batcher BPSB-010D
CB Speed Batcher BPSB-010D is engineered for weighing & portioning in seafood processing. It integrates buffer storage feeding, Z-type tank lifting, high-pressure blow drying, dual independent conveying, dual-hopper dynamic weighing, automatic material diverting & discharging, and re-weighing into one complete unit.
This fully automated unit replaces traditional discrete multi-station operation, eliminating manual intermediate transfer and re-feeding. It drastically boosts batch portioning output, weighing accuracy and overall automation level. Compatible with pollock and all other marine fish species, it suits onshore seafood plants and onboard process trawlers, supporting both single-unit operation and multi-unit parallel operation for large processing scale.
-
+Control Cabinet
-
+Frame & Workbench
-
+Weighing Hoppers
-
+Straight Conveyor
-
+Blower
-
+Z-Type Lifting Conveyor
-
+Buffer Tank
Product Features
Entire unit fabricated from 316L stainless steel for superior seawater corrosion resistance, extending service life under high-humidity, high-salt conditions onboard fishing vessels and coastal processing plants. Z-type conveyor equipped with VFD for speed regulation, matching feed capacity in real time against production output. Dual blowers with bilateral synchronous air purge to strip seawater off fish surfaces, removing moisture interference to stabilize weighing precision and avoid freezing defects during quick freezing. Dual independent straight conveyors working with twin weighing hoppers. Two separate feeding, weighing and discharging channels operate simultaneously, increase overall capacity by nearly 100% versus single-station model. Weighing hoppers with auto-opening baffles and cushioned discharge chutes prevent fish damage to preserve finished product appearance quality. Built-in re-weighing station for verification after each batch, with real-time weight data logging to guarantee consistent tray weight and reduce raw material waste.
Product Advantages
All product material is 316L stainless steel, anti-corrosion for both onshore factories and onboard processing vessels. Dual-channel synchronous portioning delivers rated capacity up to 10 batches per minute, cutting cycle time and increasing total line output. High-precision load cells plus post-process re-weighing minimize weight deviation and ensure uniform tray weight. Variable-speed feeding conveyor, customizable buffer tank capacity and adjustable target tray weight to fit multi-specification production. Few wearing parts for quick disassembly and maintenance; flexible to have parallel expansion, lower total operational cost. Sanitary washable frame design without dead zone, complying with global seafood food safety standards for exporting.
Product Specification
BPSB-010D
| Power Supply (V/Phase/Hz) | 380V / 3Ph / 50Hz |
| Buffer Tank*1 (m3) | 1.8 |
| Z-Type Conveyor *2 (kW) | 1.5 |
| Blower | 1200 m3/h, 1.1 kW, 2 units |
| Straight Conveyor (kW) | 0.37 |
| Rated Capacity*3 (min) | 10 batches/min |
| Material Weight Per Tray*4 (kg) | 12 |
Remarks：
* 1. The capacity of the buffer tank can be customized according to the layout and customer requirements.
* 2. Z-type conveyor fitted with variable-frequency motor for adjustable conveying speed.
* 3. Contact our technical team for higher throughput custom solutions.
* 4. 12 kg is the default material weight inside each tray; target weight can be adjusted upon request.
